The next generation in the successful line, the Leica S offers increased imaging quality and sensor sensitivity, predictive autofocus, higher speed and improved handling. Numerous enhanced functions contribute to the camera's further acceleration and greater security of the professional photographic workflow.

The high performance standard lens

The Summarit-S 70 mm f/2.5 ASPH. plays the role of the standard lens in the Leica S-System lens-portfolio, and has a focal length corresponding to 56 mm in 35 mm format. In order to ensure its universal versatility, the Leica design engineers invested immense effort to guarantee superior image performance at maximum aperture and at all focusing distances.

One of the eight lenses arranged in six groups features an aspherical surface, to minimize aberration effects.The two cemented elements are manufactured from glass with high anomalous partial dispersion, minimizing the effect of chromatic aberrations. In addition, glasses with very high refractive indices work together with the aspherical element to almost completely eliminate monochromatic aberration effects. In order to achieve perfect image performance from infinity to its minimum focusing distance of just 50 cm (~1.6 ft), the last two lenses are constructed as a floating element that moves independently from the rest of the optical system when focusing. The Leica Summarit-S 70 mm f/2.5 ASPH. is ideally protected against water droplets and dust and features a protective neutral glass filter that is included as a parameter in its optical design.

The reward for the immense effort invested in its design and construction is a lens with extraordinarily good contrast performance wide open and at all other apertures that, even at its closest focusing distances, can be only marginally improved in the extreme corners of images by stopping down. With a value of only 1.2%, distortion remains imperceptible, and maximum vignetting of 1.4 stops at maximum aperture is so extremely low, ensuring that the Leica Summarit-S 70 mm f/2.5 ASPH. delivers consistently dependable and superior image performance at all apertures and distances.

This is the CS version of the lens, which has a central shutter, also known as a leaf shutter, built-in. The central shutter allows the S camera to sync with a flash unit at any shutter speed up to and including 1/1000th of a second. This provides the photographer with exceptional control when balancing ambient and strobe lighting.

Specifications

Broaden Your Horizons

The Elmarit-S 30 mm f/2.8 ASPH. is equivalent, in 35 mm format, to a 24 mm super-wide-angle lens with a correspondingly expansive field of view. This, and its very fast initial aperture, makes it an ideal lens for exploring the enormous creative potentials of unusual perspectives and selective planes of focus.

When constructing super-wide lenses, immense effort must be invested to keep aberrations such as distortion or vignetting as low as possible. Five of the thirteen lenses arranged in nine groups have anomalous partial dispersion, and three of these are fluoride lenses with particularly low dispersion (colour scattering) characteristics for the correction of chromatic aberration. Two lenses are also elaborately manufactured with aspherical surfaces.

Rear-group focusing ensures consistently outstanding image performance throughout the entire focusing range and no change in the length of the lens when focusing. On top of this, its special construction provides effective protection against water droplets and dust.

Just like all other S-Lenses, the Elmarit-S 30 mm f/2.8 ASPH. is designed and constructed for maximum contrast rendition at maximum aperture, an attribute that can only be increased very slightly, and only in the extreme corners of images, by stopping down. For a lens with such a wide angle of view, its very low vignetting of only 1.5 stops and distortion of only 2.8 % (both at infinity) is negligible in practical use. Thanks to its superior imaging qualities, the creative potential offered by this super-wide-angle lens can be exploited to the full without compromise.
